Installation Steps Of Triangular Smoke Vents

Release time:

Triangular smoke vents are suitable for buildings with firefighting smoke and lighting as the mainstay, and ventilation as a supplement. According to the opening mode of the window sash, it can be divided into two types: top opening and bottom opening. Whether the installation process of the electric lighting and smoke exhaust skylight is standardized is one of the factors that determines the later service life of the smoke exhaust skylight.

What steps should be followed to install the triangular smoke vents?

1. Frame installation:

Place the roof smoke vent on the base and fix it firmly.

2. Window sash installation:

Install the smoke ventilation window sash on the window to ensure reliable fixation.

3. Installation of window opening system:

Install and fix the electric window pusher of the smoke ventilator on the installation rectangular tube, install the drive shaft and the connecting rod mechanism, and then install the window sash support rods and push rods to connect the components of the window opening system.

4. Construction of skylight electric control box and power distribution line:

Install and fix the electric control box of the smoke vent rooflight as required, and complete the construction of the line from the electric control box to the window pusher to ensure the construction specifications and the safety and reliability of the wire and line.

5. Power-on debugging of roof mounted exhaust vent:

Conduct power-on debugging for each group of smoke vents to ensure the skylights can be opened and closed flexibly, no abnormal noise, accurate window sashes, and no scratches or gaps.

Before installing the smoke vents, it is necessary to install the foundation and waterproof the surrounding area according to the relevant node practices of the architectural design drawing. The foundation should be installed vertically on the roof purlin to ensure that it is horizontal and vertical.
