Arched smoke lift continuous rooflight is good for draining rainwater in summer, and snow is not easy to accumulate in winter, so it has good self-cleaning properties. At the same time, the window sash of the continuous rooflight is FRP daylighting board, so the daylighting performance is better. The continuous rooflights can be linked with fire protection, and can be opened and closed by controlling the sense of temperature, smoke, wind, and rain.
Triple performance of ventilation, firefighting and smoke exhaust, and daylighting
Waterproof structure to eliminate water leakage
High self-clearning performance
|
Ventilator code |
Inner size of throat |
Ventilator dimensions |
Ventilator height |
|
C3G—1010n(15n,20n,25n,30n) |
1000*1000n(1500n,2000n,2500n,3000n) |
1200*（L+200） |
200 |
|
C3G—1510n |
1500*1000n(1500n,2000n,2500n,3000 n) |
1700*（L+200） |
225 |
|
C3G—2010n |
2000*1000n(1500n,2000n,2500n,3000 n) |
2200*（L+200） |
300 |
The daylighting natural ventilator’s size can be customized according to client’s requirement.
Arched continuous rooflight is widely used in logistics and warehousing, automobile and other industrial plants.
Holistic waterproof structure to prevent leakage and solve hazard.
