Automatic Opening Vent Window

The triangular smoke ventilation is composed of window, sash, lighting panel, electric window openers, control boxes, and accessories.

1. Because of triangle appearance, the makes the structure stable and not easy to deform.

2. The triangular skylight window forms a certain angle with the roof. The inclined surface design has a beautiful appearance, which is good for drainage in summer and not suitable for snow accumulation in winter, which can also reduce the load of the window on the steel structure roof.

3. The effective vent of smoke vent is basically the same with roof opening. When the skylight is fully opened, the opening angle is 90°, and the ventilation and smoke exhaust effects are the best.

4. FRP daylighting board is used as the main body of the window sash. Compared with laminated glass and sunlight board, it has higher light transmittance and better daylighting effect.

Advantages:

1. Higher light transmittance and better lighting effect.

2. It can be linked with fire fighting, the control mode is mainly general control mode, and it can also be controlled according to rain, wind, smoke, temperature, etc. Smoke vent has multiple functions of lighting, ventilation, and smoke exhaust.

Common Specifications:

Ventilator code	Inner size of throat (width*length) (mm)	Ventilator dimensions (width * length) (mm)	Ventilator height (mm)
C1ST—1010n(15n,20n,25n,30n)	1000*1000n(1500n,2000n,2500n,3000n)	1200*（L+200）	240
C1ST—1510n(15n,20n,25n,30n)	1500*1000n(1500n,2000n,2500n,3000 n)	1700*（L+200）	265
C1ST—2010n(15n,20n,25n,30n)	2000*1000n(1500n,2000n,2500n,3000 n)	2200*（L+200）	290

Ventilator code	Inner size of throat (width*length) (mm)	Ventilator dimensions (width * length) (mm)	Ventilator height (mm)
C1XT—1010n(15n,20n,25n,30n)	1000*1000n(1500n,2000n,2500n,3000n)	1200*（L+200）	430
C1XT—1510n(15n,20n,25n,30n)	1500*1000n(1500n,2000n,2500n,3000 n)	1700*（L+200）	560
C1XT—2010n(15n,20n,25n,30n)	2000*1000n(1500n,2000n,2500n,3000 n)	2200*（L+200）	680

The size can be customized according to client’s requirement.

Scope of Application:

It is widely used in various fields such as steel, automobiles, logistics, machining, metallurgy, etc.

Waterproof Method:

As a professional smoke vents manufacturer, Mcwell choose "nail-free and glue-free waterproof structure" patented technology to produce smoke exhaust ventilator, which do not require any silica gel, self-tapping nails, drilling or rivets; the window sash and the window body are all integrated holistically into the waterproof structure, there is no self-tapping screw, rivet, screw or bolt that destroy the integrated structure, and waterproofing completely relies on its own structure.
