Automatic opening vent is ventilation and smoke-exhausting equipment which is frequently used in modern industrial plants. Smoke vents mainly meet the fire-fighting smoke exhaust requirements of the workshops. The smoke ventilator can be controlled by temperature, smoke, fog, rain and other forms. Because the factory and workshop are often in a normally closed state, once an emergency occurs, the windows need to be opened in time to quickly exhaust the dense smoke.
Nail-free and glue-free waterproof structure can completely eliminate water leakage.
Connect with firefighting service and offer multiple functions which include smoke exhaust, ventilation and lighting.
Easy to install and operate.
|
Ventilator code |
Inner size of throat |
Ventilator dimensions |
Ventilator height |
|
C1ST—1010n(15n,20n,25n,30n) |
1000*1000n(1500n,2000n,2500n,3000n) |
1200*（L+200） |
240 |
|
C1ST—1510n(15n,20n,25n,30n) |
1500*1000n(1500n,2000n,2500n,3000 n) |
1700*（L+200） |
265 |
|
C1ST—2010n(15n,20n,25n,30n) |
2000*1000n(1500n,2000n,2500n,3000 n) |
2200*（L+200） |
290 |
|
Ventilator code |
Inner size of throat |
Ventilator dimensions |
Ventilator height |
|
C1XT—1010n(15n,20n,25n,30n) |
1000*1000n(1500n,2000n,2500n,3000n) |
1200*（L+200） |
430 |
|
C1XT—1510n(15n,20n,25n,30n) |
1500*1000n(1500n,2000n,2500n,3000 n) |
1700*（L+200） |
560 |
|
C1XT—2010n(15n,20n,25n,30n) |
2000*1000n(1500n,2000n,2500n,3000 n) |
2200*（L+200） |
680 |
Size can be customized according to client’s requirement.
It is widely used for industries plants such as automobiles, manufacturing, e-commerce, storage, and spare parts.
The smoke ventilator accept "Nail-free and glue-free waterproof structure" technology, which can completely solve water leakage hazard.
