Metal Building Ridge Vents

Due to the beautiful appearance design and efficient ventilation effects, streamlined metal building ridge vents are widely used for many industrial plants. The ridge ventilator is composed of frame, outer guard plate, rainproof plate, drainage groove, valve plate, electric or manual actuator. Natural roof ventilation is classified according to the size of the throat.

Advantages:

Adopt the patented technology of “holistic waterproof structure”, no leakage hazard
The skeleton adopts hot-dip galvanized steel sheet integral hydraulic forming, with good stability and good anti-corrosion performance
Evenly distributed on the sloping roof to ensure balanced ventilation, smoke exhaust and lighting
Standardized mass production, quick installation, high cost performance

Common Specifications:

Ventilator code	Throat width(mm)	Throat length(mm)	Ventilator height(mm)
MCW6HD—0612n MCW6HD—0615n	600	1200n、1500n	730
MCW6HD—0712n MCW6HD—0715n	700	1200n、1500n	820
MCW6HD—0812n MCW6HD—0815n	800	1200n、1500n	850
