Light-weight natural ventilator is widely used in industrial plants, because roof louver vent has the functions of low height, light weight, low steel consumption, and a wide range of applications, including automobiles, warehousing, logistics, furniture, manufacturing, etc. The rainproof board of the exhaust louvers and vents is FRP daylighting board, which can take into account the function of natural lighting and meet the needs of natural lighting inside the factory.
Three-layer rain-proof board structure, splash-proof rain, good rain and fog performance
The resistance coefficient of the low-profile natural ventilator is about 3.8, which is only about 1/4 of that of the general low-profile ventilator
Low height, top-notch wind resistance, maximum resistance to level 15 typhoons, especially suitable for typhoon areas
The labyrinth industrial ventilator truly achieves an effective ventilation area >50%
Low deadweight reduces roof load and steel consumption in construction
| Ventilator code |
Throat width (mm) |
Throat length (mm) |
Ventilator height (mm) |
| MCW1H(Z)—1220n | 1200 | 2000*n | 560 |
| MCW1H(Z)—1520n | 1500 | 2000*n | 560 |
The roof louver vent’s size can be customized according to client’s requirement.
The natural ventilation system is widely used for metallurgy, machinery, chemical industry, electronics, logistic warehouse, shipbuilding, etc.
Roof louver vent is holistic waterproof structure, which relies on it's own structure for waterproofing.
